Dimensions:
Height: 43.2 cm
Width: 8.5 cm
Depth: 58.4 cm
Weight: 25.0 kg
Operating Temperature: 0 – 40 °C
Storage Temperature: -15 – 45 °C
Battery Type: Lead-acid
Typical Recharge Time: 3 hours
Battery Life: 3 – 5 years
Max Configurable Power: 1.98kW / 2.2kVA
Transfer Time: 0 ms (zero transfer time)
Noise Level: 55 dBA at 1 meter
Output Power Capacity: 2.2kVA / 1.98kW
Input Connection Types:
BS1363A British
IEC 60320 C20
Schuko CEE 7 / EU1-16P
Output Connections:
8x IEC 320 C13 (Battery Backup)
2x IEC 60320 C19 (Battery Backup)
2x IEC Jumpers (Battery Backup)
Nominal Output Voltage: 230V
SmartSlot: Customize UPS capabilities with management cards.
...
- Dimensions:
- Height: 43.2 cm
- Width: 8.5 cm
- Depth: 58.4 cm
- Weight: 25.0 kg
- Operating Temperature: 0 – 40 °C
- Storage Temperature: -15 – 45 °C
- Battery Type: Lead-acid
- Typical Recharge Time: 3 hours
- Battery Life: 3 – 5 years
- Max Configurable Power: 1.98kW / 2.2kVA
- Transfer Time: 0 ms (zero transfer time)
- Noise Level: 55 dBA at 1 meter
- Output Power Capacity: 2.2kVA / 1.98kW
- Input Connection Types:
- BS1363A British
- IEC 60320 C20
- Schuko CEE 7 / EU1-16P
- Output Connections:
- 8x IEC 320 C13 (Battery Backup)
- 2x IEC 60320 C19 (Battery Backup)
- 2x IEC Jumpers (Battery Backup)
- Nominal Output Voltage: 230V
- SmartSlot: Customize UPS capabilities with management cards.
- LCD Graphics Display: Shows modes of operation, system parameters, and alarms.
- ECO Mode: Enhances efficiency by bypassing unused components during good power conditions.
